Resolution 3D AOI Stencil Inspection Machine SVII-K100 Ethernet/Wifi Interface 220V AC

Product Description:

The SVII-K100 Stencil Inspection Machine System represents a pinnacle of precision engineering, designed to cater to the intricate needs of stencil inspection within various industrial applications. This state-of-the-art system boasts a high-resolution imaging capability down to 10μm, making it an ideal solution for detecting minute flaws and ensuring the highest standards of quality control. The SVII-K100 model is specifically tailored to address the complexities involved in stencil inspection processes, which demand not only accuracy but also efficiency and reliability.

At the core of the SVII-K100 Stencil Inspection Machine System is its advanced optical system, which provides a field of view of up to 18.6 mm x 14 mm. This extensive field of view allows for a comprehensive inspection of stencils in a single pass, significantly reducing the inspection time and increasing throughput. The system's high-resolution capabilities ensure that even the smallest of defects can be identified with precision, thereby preventing potential errors in subsequent stages of the manufacturing process.

Powered by a robust Windows 10 operating system, the SVII-K100 Stencil Inspection Machine System offers an intuitive user interface that simplifies the complex process of stencil inspection. Windows 10 provides a stable platform for the machine's software to run on, ensuring seamless operation and compatibility with a wide range of supporting applications and peripherals. This integration of a familiar operating system also means that operators can benefit from a reduced learning curve, allowing for a quick adaptation to the machine's functionalities.

The application of the SVII-K100 Stencil Inspection Machine System extends across various industries where precision is paramount. In electronics manufacturing, for example, the system can be utilized to inspect solder paste stencils, which are critical for ensuring the quality and reliability of printed circuit boards (PCBs). By identifying defects such as bridging, smearing, or insufficient paste deposits, the SVII-K100 helps maintain the integrity of the soldering process and prevents costly rework and product failures.

Furthermore, the stencil inspection machine has been engineered with versatility in mind. Its adaptability to different stencil sizes and types makes it a valuable asset in a production environment where flexibility is required. Whether dealing with small batch production or high-volume runs, the SVII-K100 can be configured to meet the specific inspection needs of the task at hand. This versatility ensures that the machine remains a critical component in the quality assurance process across various production scenarios.

The reliability of the SVII-K100 Stencil Inspection Machine System is backed by rigorous testing and quality assurance measures. Each machine undergoes extensive calibration and validation to ensure that it performs consistently to the highest standards. This commitment to quality is reflected in the machine's durable construction and the use of high-grade components, which guarantee a long service life and minimal maintenance requirements.

In conclusion, the SVII-K100 Stencil Inspection Machine System is an invaluable tool for any operation where stencil inspection is crucial. Its high-resolution imaging, expansive field of view, and integration with Windows 10 create a powerful solution that enhances quality control processes. The versatility and reliability of the SVII-K100 make it a must-have for industries looking to maintain the highest standards of precision and efficiency. By incorporating this stencil inspection machine into their workflow, businesses can achieve superior product quality and gain a competitive edge in their respective markets.

Features:

• Product Name: Stencil Inspection Machine System
• Lighting System:
  • Top: Red Coaxial Light
  • Bottom: Custom White LED Light Source
• Weight: 830kg
• Interface: Ethernet/Wifi
• Resolution: 10μm
• Inspection Speed: Up to 0.5/s per FOV

Technical Parameters:

Applications:

The Sunmenta SVII-K100 is a state-of-the-art stencil inspection machine designed to meet the rigorous demands of modern manufacturing. Originating from China, the SVII-K100 carries the prestigious CE certification, ensuring its compliance with European standards for health, safety, and environmental protection. Ideal for electronics assembly lines, the machine offers a comprehensive solution for ensuring the quality and precision of solder paste application.

With a minimum order quantity of one unit, the Sunmenta stencil inspection machine is accessible for both large-scale operations and smaller, specialized manufacturers. The SVII-K100 model boasts a compact footprint with dimensions of 1130mm X 1215mm X 1500mm, making it a versatile addition to any production floor without requiring significant space allocation.

One of the key application occasions for the Sunmenta stencil inspection machine is during the initial stages of the Surface Mount Technology (SMT) process. Here, it performs detailed inspections of solder paste deposits on PCB stencils, ensuring that any potential printing errors are detected early on, thus preventing costly defects down the line. The system is capable of inspecting stencils at an impressive speed of up to 0.5 seconds per Field of View (FOV), with a FOV measuring up to 18.6 mm X 14 mm, facilitating rapid and efficient quality control.

The advanced connectivity options of the SVII-K100, including both Ethernet and Wifi interfaces, allow for seamless integration into existing production networks. This ensures real-time data communication and enables the machine to be part of a smart factory environment, optimizing the inspection process through better data management and analysis.

The Sunmenta stencil inspection machine is equipped with a sophisticated lighting system comprising of red coaxial light from the top and a custom white LED light source from the bottom. This innovative lighting setup enhances the contrast and detail visibility of the stencil patterns, allowing for more accurate inspections.

Scenarios where the Sunmenta SVII-K100 stencil inspection machine truly shines include high-precision manufacturing environments where the margin for error is minimal. The electronics industry, particularly those involved in the production of smartphones, medical devices, and automotive electronics, can benefit greatly from the precision and reliability offered by the SVII-K100.

Overall, the Sunmenta stencil inspection machine is a crucial tool for any operation where stencil-based solder paste application is pivotal to the product quality. With its rapid inspection capability, advanced lighting, and robust connectivity, the SVII-K100 ensures that only the highest quality stencils proceed to the next stage of the production process, safeguarding the integrity of the final products.

Customization:

Brand Name: Sunmenta

Model Number: SVII-K100

Place of Origin: China

Certification: CE

Minimum Order Quantity: 1

Dimensions: 1130mm X 1215mm X 1500mm

Inspection Method: 3D AOI

Lighting System: Top: Red Coaxial Light, Bottom: Custom White LED Light Source

Resolution: 10μm

Application: Stencil Inspection

Introducing the Sunmenta SVII-K100, a state-of-the-art stencil inspection machine designed for high-precision stencil analysis. This cutting-edge stencil inspection machine is crafted with the expertise of our engineers in China, ensuring top-quality manufacturing and performance. Our stencil inspection machine comes with a CE certification, reflecting our commitment to quality and safety standards. With a compact footprint of 1130mm X 1215mm X 1500mm, it is equipped with an advanced 3D AOI inspection method and a sophisticated lighting system featuring top red coaxial light and a custom white LED light source for bottom illumination. The SVII-K100 boasts a high resolution of 10μm, making it ideal for precise stencil inspection applications in various industries.

Support and Services:

Our Stencil Inspection Machine System is designed to provide reliable and accurate inspection to ensure the highest quality in your printing processes. To support your ongoing success, we offer a comprehensive suite of technical support and services, tailored to meet the unique needs of your operations.

Technical Support Services:

• Remote Assistance: Our team of experts is available to provide remote troubleshooting and guidance to resolve any issues that may arise, ensuring minimal downtime and maximum productivity.

• Software Updates: Regular software updates are provided to enhance features, improve usability, and ensure your system is protected against the latest security threats.

• On-site Support: In cases where remote assistance is not sufficient, we can deploy technical support professionals to your location for hands-on service and support.

Preventative Maintenance Services:

• System Calibration: We offer routine calibration services to maintain optimal performance and accuracy of your Stencil Inspection Machine System.

• Equipment Health Checks: Our technicians can conduct comprehensive equipment inspections to identify and address potential issues before they lead to downtime.

• Replacement Parts and Repairs: We maintain a stock of genuine replacement parts to ensure quick repairs and replacements, keeping your system in top condition.

Training Services:

• Operator Training: We provide detailed training sessions for operators to ensure they are fully proficient in using the Stencil Inspection Machine System and its software.

• Advanced User Training: For more experienced users, we offer advanced training to help them leverage the full capabilities of the system.

Consultation Services:

• Process Optimization: Our experts can help you optimize your stencil inspection processes for improved efficiency and quality outcomes.

• Custom Solutions: If you have specific challenges or requirements, we can work with you to develop custom solutions that integrate seamlessly with your existing workflows.

For any support requests or to learn more about our services, please reach out to our customer support team. We are dedicated to providing you with outstanding support to ensure your Stencil Inspection Machine System operates at its best.
